 HOME > 제품소개 > 설비 > ARO SYSTEM |
|
|
ARO-150G |
ARO-150GN |
20"5 micron Prefilter |
20"1 micron Prefilter |
20" Carbon block Prefilter |
Anti-Scalent Prefilter |
Booster Pump & Transformr |
TFC R.O. membranes(75gpd*2) |
Post Granular Carbon filter |
High/Low Pressure Swtich |
Auto Shut-off Valve |
Flow Restrictor |
Faucet & Installation kit |
Auto Flush Controller(option) |
Solenoid Valve 3/8", 1/4" |
Shipping Dimension & weight: |
48x26x83cm 20kgs |
|
|
ARO-200G/G-N 300G/G-N
31.5L/H 47.3L/H |
|
ARO-200G/G-N |
ARO-300G/G-N |
20" 5 micron Prefilter |
20" 1 micron Prefilter |
20" Carbon block Prefilter |
Anti-Scalent Prefilter |
Booster Pump & Transformer * 2sets * 3sets |
TFC R.O. membranes(100gpd*2, *3) |
Post Granular Carbon filter |
High/Low Pressure Swtich |
Faucet & Installation kit |
Auto Flush Controller(option) |
Solenoid Valve 3/8", 1/4" |
Shipping Dimension & Weight |
48x32x83cm 28kgs (ARO-200G) |
48x32x83cm 28.3kgs (ARO-300G) |
|
|
|
ARO-400G |
ARO-400G-N |
20" 5 micron Prefilter |
20" 1 micron Prefilter |
20" Carbon block Prefilter |
Anti-Scalent Prefilter |
Booster Pump & Transformer * 4 sets |
TFC R.O. membranes(100gpd*4) |
Post Granular Carbon filter |
High/Low Pressure Swtich |
Faucet & Installation kit |
Auto Flush Controller(option) |
Solenoid Valve 3/8", 1/4" |
Shipping Dimension & Weight |
48x32x83cm 29kgs |
|
|
ARO-300G-2/500G-2
47.3L/H 78.8L/H |
|
ARO-300G-2 |
ARO-500G-2 |
S.steel frame |
20" Prefilters x 3 |
S.steel Membrane vessel (*2) |
2.5" x 21" membrane (*2) |
inlet & Flush Solenoid Valve |
Source & Ro Gauge |
Inlet & Concentration Flow meter |
100gph vane pump & 1/2hp motor |
Auto Flush Controller |
Pressure Regulator |
Anti-scalent device |
Electricity consumption:392W |
Shipping dimension & weight: |
48x60x72cm 35kgs (300G-2) |
48x60x72cm 36kgs (600G-2) |
|
|
|
ARO-800G |
S.steel frame |
20" Prefilters x 3 |
S.steel Membrane vessel |
4"x21" membrane |
Inlet & Flush Solenoid Valve |
Source & Ro Gauge |
Inlet & Concentration Flow meter |
240gph vane pump & 1hp motor |
Auto Flush Controller |
TDS detector |
Pressure Regulator |
Anti-scalent device |
Electricity consumption: 764W |
Shipping dimension & weight: |
80x50x116cm 60kgs |
|
|
ARO-1500G/2000G
236.5L/H 315.4L/H |
|
ARO-1500G UP TO 2000G |
S.steel frame |
20" Prefilters x 3 |
Fiber Glass Membrane vessel |
4"x40" membrane |
Inlet & Flush Solenoid Valve |
Source & Ro Gauge |
Inlet & Concentration Flow meter |
240gph vane pump & 1hp motor |
Auto Flush Controller |
TDS detector |
Pressure Regulator |
Anti-scalent device |
Electricity consumption: 764W |
Shipping dimension & weight: |
80x50x145cm 65kgs |
|
|
ARO-3000G/4000G
473.1L/H 630.8L/H |
|
ARO-3000G UP TO 4000G |
S.steel frame |
20" Prefilters x 3 |
Fiber Glass Membrane vessel*2 |
4"x40" membrane*2 |
Inlet Actuator & Flush Solenoid Valve |
Source & Ro Gauge |
Inlet & Concentration Flow meter |
S.steel Vertical Pump 1.1kW |
(single phase motor) |
Auto Flush Controller |
TDS detector |
Pressure Regulator |
Gate Valve |
Anti-scalent device*2 |
Electricity consumption: 1120W |
Shipping Dimension & weight: |
80x50x145cm 78kgs |
|
|
ARO-4500G/5500G
709.6L/H 867.3L/H |
|
ARO-4500G UP TO 5500G |
S.steel frame |
20" Prefilters x 3 |
Fiber Glass Membrane vessel*3 |
4"x40" membrane*3 |
Inlet Actuator & Flush Solenoid Valve |
Source & Ro Gauge |
Inlet & Concentration Flow meter |
S.steel Vertical Pump 2.2kW |
(single phase motor) |
Auto Flush Controller |
TDS detector |
Pressure Regulator |
Gate Valve |
Anti-scalent device*3 |
Electricity consumption: 2220W |
Shipping Dimension & weight: |
80x50x145cm 88kgs |
|
|
ARO-6000G/8000G
946.2L/H 1,261.6L/H |
|
ARO-6000G UP TO 8000G |
S.steel frame |
Fiber Glass Membrane vessel*4 |
4"x40" membrane*4 |
Inlet Actuator & Flush Solenoid Valve |
Source & Ro Gauge |
Inlet & Concentration Flow meter |
S.steel Vertical Pump 2.2kW |
(single phase motor) |
Auto Flush Controller |
TDS detector |
Accumulated timer |
Pressure Regulator |
Gate Valve |
Anti-scalent device*4 |
Electricity consumption: 2220W |
Shipping Dimension & weight: |
80x50x145cm 88kgs |
|
|
ARO-10000G/12000G
1.577.OL/H 1,892.5L/H |
|
ARO-10000G UP TO 12000G |
S.steel frame |
Fiber Glass Membrane vessel*6 |
4"x40" membrane*6 |
Inlet & Flush Solenoid Valve |
Source & Ro Gauge |
Inlet & Concentration Flow meter |
S.steel Vertical Pump 4.0kW |
(three phase motor) |
Auto Flush Controller |
TDS detector |
Accumulated Regulator |
Gate Valve |
Anti-scalent device*6 |
Electricity consumption: 4020W |
Shipping Dimension & weight: |
112x101x150cm 120kgs |
|
|
ARO-14000G/15000G
2,207.9L/H 2,365.6L/H |
|
ARO-14000G UP TO 15000G |
S.steel frame |
Fiber Glass Membrane vessel*8 |
4"x40" membrane*8 |
Inlet Actuator & Flush Solenoid Valve |
Source & Ro Gauge |
Inlet & Concentration Flow meter |
S.steel Vertical Pump 4.0kW |
(three phase motor) |
Auto Flush Controller |
TDS detector |
Accumulated timer |
pressure Regulator |
Gate Valve |
Anti-scalent device*8 |
Electricity consumption: 4020W |
Shipping Dimension & weight: |
112x101x150cm |
|
|
| |
NON-STANDARD CHOICE
Through years experiences, continuous effort in water treatment, we worked
out different types of water facilities, cost, maintenance and environmental
study, we concern more than clients.
|
| |
 |
| |
 |
| |
WATER TREATMENT FACILITIES:
| * Pump + Motor |
* Water Softener |
| * Cluster Filter |
* Reverse Osmosis Main Unit |
| * Filtration System |
* UV Sterilizer |
|
| |
 |
| |
| |
|
